Radar Sport
Estimated Arrival: Late Spring
Radar: A system for detecting the presence, direction, distance, and speed of surrounding conditions.
The dirt is your environment. Radar is your frequency for feeling it. Agile, composed, sharp, and rugged, Radar is an apparatus for experience. If you want to unplug from the machine and remember what it means to explore the wild, this is your signal.
- Off-road geometry in butted chromoly steel.
- 3 pack mounts on down tube, fork legs and chainstay. Bottle mounts on seat tube and downtube. Bento box mount on top tube. Fender and rack mounts. Bring it on.
- Shimano Deore, 12 speed drivetrain with 10-51T Deore cassette.
- WTB tubeless ready tires & rims.
- Clears up to 29” x 2.4” tires.
Equipment - Radar Sport
Specifications
FRAME & FORK
Frame: Breezer 4130 Butted Chromoly Steel, tapered head tube 1 1/8" to 1 1/2", 148mm rear spacing, UDH compatible, three pack mount on top of down tube and driveside seatstay, waterbottle mount on seat tube and bottom of down tube, bento box mount on to tube,fender and rear rack mount, flat mount disc brake
Fork: Breezer 4130 Chromoly, tapered 1 1/8 to 1 1/2 steerer tube, three pack mount on each fork leg, fender mount, 15 x 110 thru axle drop out, 51mm offset, flat mount disc brake
DRIVETRAIN
Crankset: Alloy crank, 170mm XS-L, 175mm XL-XXL, steel narrow side chainring 34T
BB: Outboard cartridge bearing
Rear Derailleur: Shimano Deore Shadow Plus, 12 speed
Right Shifter: Shimano Deore Rapid Fire Plus, 12 speed
Cassette: Shimano Deore 10-51T
Chain: KMC x12 EPT Anti Rust
WHEELSET
Rims: WTB ST i30 TCS 2.0, 32H, tubeless ready
Spokes: Pillar, 14 gauge, butted
Front Hub: KT, sealed cartridge bearing, Center Lock
Rear Hub: KT, sealed cartridge bearing, Center Lock, Microspline
Tires: WTB Nineline 29 x 2.25 TCS Light/Fast rolling 60 TPI
BRAKES
Brakes: TRP HD-R803
Brake Levers: TRP HD-R803
Front Rotor: TRP Center Lock, 180mm
Rear Rotor: TRP Center Lock, 160mm
COCKPIT & CONTACT POINTS
Handlebar: Alloy, 780mm width, 15mm rise, 9° backsweep, 31.8 clamp diameter
Grips: WTB Solano single sided lock on
Stem: Alloy, 45mm reach XS-L, 55mm reach XL-XXL, 31.8mm clamp
Headset: FSA
Saddle: WTB Solano medium, chromoly rail
Seatpost: 6061 aluminum 27.2 x 350mm
Seatpost Clamp: Alloy
FIT & DETAILS
Color: Low Pressure (Glossy Gray)
Weight: 30.4 lbs (size large)
