Radar Expert
Description
The RADAR is the ultimate Road And Dirt Adventure Rig. Let RADAR set your bearings toward determined velocities of distant desire. Constructed using a double-butted Chromoly frame and fork that features rack mounts, five (yes, five) water bottle mounts, disc brakes, and clearance for off-road tires. The RADAR is the perfect choice for urban adventures, full-blown bikepacking, or anything in between. Wide range gearing will get you up the steepest climbs and back down again even when fully loaded with gear.
Features
• Breezer off road capable geometry
• Butted CrMo with English threaded bottom bracket
• Compatible with off road tires
• Ready for racks and extra bottle cages
• Tubeless-compatible wheelset
• Tire Clearance: 700c x 45mm
30-Day Return Policy
Ship to Home Return Policy
Item(s) in new, unassembled, unused condition and with all original packaging, hangtags, and parts will be eligible for a refund when returned within 30 days of purchase. Return shipping fees apply.
*More Details
Ship to Store Return Policy
Bicycles can be returned at time of pick-up only. After leaving the store with your assembled bicycle the sale is final. It’s up to the seller you purchased from to initiate the return. Restocking fee may apply.
*More Details
Assembly Instructions
Breezer Bikes ship partially assembled from the factory. We always recommend that a trained mechanic build your bike, but if you follow the assembly video and take your time, you can build the bike yourself.
Watch Assembly Video
The perfect adventure bike for:
The rider needing a do-it-all bike to tackle any terrain. Whether it's battling potholes or navigating mountain passes, the Radar series is built for the rider who doesn't want to be limited to the pavement.
engineered with
Compact Geometry
Joe's compact geometry allows riders to enjoy greater standover clearance for navigating technical terrain, shave weight off the frame, and allow for a wider range of adjustability for riders of different sizes.
Made with
Breezer Steel
The staple material for most Breezer bikes, Breezer Steel 4130 Chromo offers incredible durability, excellent shock-absorbing qualities, and fully-butted tube walls for reduced weight.
Equipped with
Multiple Mounts
Designed to be customized for your adventure Breezer's multi-mount technology allows options for waterbottle cages, racks, and fenders.
Equipped with
Breeze-In Dropouts
The iconic Breeze-in dropouts create increased strength and ridigity in the rear triangle and offers a lighter weight alternative to standard dropouts.
Specifications
| Sizes | Compact: XS (45cm), S (48cm), M (51cm), L (54cm), XL (57cm), XXL (60cm) |
| Color(s) | Cherry-cola red |
| Frame | Breezer butted chromoly steel, BSA threaded BB , Apex disc mount 135mm QR |
| Fork | Chromoly disc, 1 1/8", QR w/rack, fender & side bottle mounts |
| Crankset | Breezer 2-pc w/hollow axle, 46/30T |
| Bottom Bracket | Breezer External Sealed Bearing, BSA |
| Pedals | N/A |
| Front Derailleur | microSHIFT R9 |
| Rear Derailleur | microSHIFT R9 |
| Shifters | microSHIFT R9 |
| Cassette | microSHIFT H92, 9-Speed |
| Chain | KMC X9, 9spd |
| Wheelset | WTB STP i23 TCS disc, tubeless compatible, Formula sealed bearing hubs, 14g SS spokes, 32H |
| Tires | WTB Riddler Comp, 700 x 45c, wire bead |
| Brakeset | TRP HY/RD hydraulic caliper, 160mm rotors |
| Brake Levers | microSHIFT |
| Headset | FSA 1 1/8" Threadless, 6.5mm aluminum top cover |
| Handlebar | Breezer, 6061 alloy, 31.8mm clamp, 125mm drop, 25° flare, 4° sweep |
| Stem | Breezer B-Road, 3D-forged 6061 stem body, +/-6° |
| Tape | Selle San Marco Presa Corsa Dynamic |
| Saddle | Selle San Marco Monza Full Start Up |
| Seatpost | Breezer setback, 6061 alloy, 27.2mm diameter |
| Weight | 13.09kg / 28.86lbs |
Due to COVID related supply chain issues component specification could change at any time without notice.
Geometry
| Size(*Compact Frame) | XS | S | M | L | XL | XXL | |||||
| Bike Size(*Compact Frame) | 45cm | 48cm | 51cm | 54cm | 57cm | 60cm | |||||
| A | Seat Tube, Center to Top | 450 | 480 | 510 | 540 | 570 | 600 | ||||
| C | Top Tube, Effective | 565 | 575 | 585 | 595 | 608 | 627 | ||||
| D | Head Tube Length | 120 | 120 | 155 | 170 | 170 | 190 | ||||
| E | Seat Tube Angle | 74° | 72.5° | 72.5° | 72.5° | 72.5° | 72.5° | ||||
| G | Head Tube Angle | 70.5° | 71.5° | 71.5° | 71.5° | 71.5° | 71.5.° | ||||
| H | Chainstay Length | 457 | 457 | 457 | 457 | 457 | 457 | ||||
| I | Wheelbase | 1068 | 1068 | 1070 | 1080 | 1093 | 1113 | ||||
| J | Bottom Bracket Drop | 75 | 75 | 75 | 75 | 75 | 75 | ||||
| K | Fork Offset | 45 | 45 | 45 | 45 | 45 | 45 | ||||
| M | Stack | 576 | 598 | 612.6 | 627 | 627 | 645.8 | ||||
| N | Reach | 393 | 386 | 391.4 | 397 | 410 | 424 | ||||
| O | Standover | 711.52 | 736.22 | 762.67 | 792.38 | 817 | 842 | ||||
| Stem mm | 70 | 80 | 80 | 90 | 100 | 100 | |||||
| Handlebar Width cm | 40 | 42 | 42 | 44 | 44 | 46 | |||||
| Crank mm | 170 | 170 | 175 | 175 | 175 | 175 | |||||
| Wheel Size | 700c | 700c | 700c | 700c | 700c | 700c | |||||
| Seat Post Diameter mm | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
