Radar X Pro

Sale price $999.96 USD Regular price $1,999.99

18 reviews
Size
Color: Deep Purple
Description

If you're a fan of drop bars on dirt trails, then the RADAR X is the bike for you. Built on a supple steel frame and fork with 29" x 2.0" tires the RADAR X smooths out rough trails and gravel roads. The frame & fork feature multiple braze-ons for bags and bottle mounts so you can load out on epic bikepacking adventures as well. If you are looking for a ride for ripping singletrack or exploring far into the wild the RADAR X has you covered.


Features

• Breezer off road capable geometry
• Butted CrMo with English threaded bottom bracket
• Compatible with off road tires
• Ready for racks and extra bottle cages
• Tubeless-compatible wheelset
• Tire clearance: 29"x2.4"

Assembly Instructions

Breezer Bikes ship partially assembled from the factory. We always recommend that a trained mechanic build your bike, but if you follow the assembly video and take your time, you can build the bike yourself.

Watch Assembly Video

Specifications

SizesXS (45cm), S (48cm), M (51cm), L (54cm), XL (57cm), XXL (60cm)
Color(s)Deep Purple
FrameBreezer butted chromoly steel, BSA threaded BB, Boost 148mm thru-axle
ForkChromoly disc, rack / fender & side bottle mounts, Boost 110 x 15mm thru-axle
CranksetFSA Afterburner Modular DM, 38T
Bottom BracketFSA Mega-Exo BSA
PedalsN/A
Rear DerailleurShimano GRX 812, long cage
ShiftersShimano GRX 600, 1x11-speed
CassetteShimano Deore, 11-42T, 11-speed
ChainKMC X11
WheelsetWTB ST i23 TCS disc, tubeless compatible, Formula sealed bearing hubs, 14g SS spokes, 32H
TiresWTB Nineline TCS, 29 x 2.25, TCS Tubeless Ready, Lightweight Casing, Dual DNA Compound
BrakesetShimano GRX hydraulic, 160mm rotors
Brake LeversShimano GRX
HeadsetFSA 1 1/8" Semi-Integrated, 36 degree ACB-sealed, 6.5mm aluminum top cover
HandlebarBreezer Big Bar, 6061 alloy, 31.8mm clamp, 46-50cm width, 12 degree flare
StemBreezer B-Road, 3D-forged 6061 stem body, +/-7 degree
TapeSelle San Marco Presa Corsa Dynamic
SaddleSelle San Marco RND Start Up
SeatpostBreezer setback, 6061 alloy, 30.9mm diameter
Weight13.90kgs / 30.64lbs

Due to COVID related supply chain issues component specification could change at any time without notice.

Geometry

 Size(*Compact Frame)XSSMLXLXXL
 Bike Size(*Compact Frame)45cm48cm51cm54cm57cm60cm
ASeat Tube, Center to Top450480510540570600
CTop Tube, Effective580590600610623642
DHead Tube Length120120155170170190
ESeat Tube Angle74°73.5°73°73°73°73°
GHead Tube Angle69°69°69°69°69°69°
HChainstay Length444444444444444444
IWheelbase109911031110112211361155
JBottom Bracket Drop757575757575
KFork Offset515151515151
MStack568568601615615633
NReach417421421422435448
OStandover775788818839853872
 Stem mm707080808090
 Handlebar Width cm484850505050
 Crank mm170170175175175175
 Wheel Size700c700c700c700c700c700c
 Seat Post Diameter mm30.930.930.930.930.930.9
